- My research lies in the field of beamforming for mmWave Communications.
Radiation Pattern by tweaking number of Antennas
- From the above graph, we can see that Antenna gain proportional to number of antennas. More the number of antennas, more the beamforming gain and less Half Power Band Width(HPBW).
Radition Pattern by tweaking d/lamda
- From the above graph, we can see the ratio of 0.5 yields only one main lobe. Ratio of >0.5 creates significant side lobes resulting in power leakage in not desirable directions.
Additional Resources
Slides on Basic Beamforming
Code for above animation
